Devices (Addressable)

Addressable System Modules & Expanders

This category groups Silent Knight add-on hardware for addressable systems: SBUS modules that expand the panel, plus SD addressable devices. The 5815XL signaling line circuit controller adds 99 SK modules and 99 SK devices or 127 SD addressable devices to an IntelliKnight 5820XL or 5820XL-EVS panel, and the 6815 is an SLC loop expander for SK devices.

The 5880 LED I/O driver module provides 40 programmable LED outputs and eight supervised dry contact inputs for custom remote annunciation, the 5824 serial/parallel gateway module connects a PC-compatible printer to the IntelliKnight system, and the 5496 is a 6 amp notification power expander with its own AC power connection and battery charging circuit. SK-NIC network interface cards, SK-FSL and SK-FML fiber cards, and the SD505-6RB 6" relay base with one Form "C" contact round out the group.

Shop SBUS devices or addressable SD SLC devices. Browse the full Silent Knight catalog. Contact our team for panel compatibility questions.
